Chemical and Petrochemical
Goodall knows chemical. Over 40 years ago we invented Goodall Kemflex, the first hose specifically formulated for a broad spectrum of chemicals.
Nearly half a century later, the latest version of Kemflex is still the industry benchmark.
It's the most resilient, best-build chemical hose that money can buy.
Kemflex SD
Internal diameter
13 mm to 100 mm
Work Pressure
20 bar
Temperature
-40 °C to 100 °C
- Superior design for use in chemical plants, ship, barge and tank truck service
- Exceptional flexible chemical hose for suction and discharge applications
- Designed with fully conductive rubber compounds for added safety, ideal for applications in which static electricity can occur
- Classification Grade Ω/T
- Exceeds EN 12115
Acidkem D
Internal diameter
13 mm to 100 mm
Work Pressure
20 bar
Temperature
-40 °C to 95 °C
- Exceptional flexible chemical hose for discharge applications for different types of acids, alkalis, esters and ketones
- Superior design for use in chemical plants, ship, barge and tank truck service
- Designed with fully conductive rubber compounds for added safety, ideal for applications in which static electricity can occur
- Classification Grade Ω/T
- Exceeds EN 12115
Acidkem SD
Internal diameter
19 mm to 100 mm
Work Pressure
20 bar
Temperature
-40 °C to 95 °C
- Exceptional flexible chemical hose for discharge applications for different types of acids, alkalis, esters and ketones
- Superior design for use in chemical plants, ship, barge and tank truck service
- Designed with fully conductive rubber compounds for added safety, ideal for applications in which static electricity can occur
- Classification Grade Ω/T
- Exceeds EN 12115
Tekno SD
Internal diameter
13 mm to 100 mm
Work Pressure
16 bar
Temperature
-40 °C to 82,2 °C
- Developed for use in chemical plants, ship, barge and tank truck service
- Designed with fully conductive rubber compounds for added safety
- Classification Grade Ω/T
- EN 12115
Solveco SD
Internal diameter
19 mm to 102 mm
Work Pressure
16 bar
Temperature
-35 °C to +95 °C
- Flexible suction and discharge hose developed to handle chemical products such as acids, alkalis, esters and ketones
- In accordance with
EN 12115:2021
Nitrogen
Internal diameter
13 mm to 25 mm
Work Pressure
20 bar
Temperature
-40 °C to 80 °C
- For use in nitrogen service to purge lines in refineries, petrochemical, and general industries
- Designed with fully conductive rubber compounds for added safety
- Classification Grade Ω/T
Diamond D
Internal diameter
13 mm to 50 mm
Work Pressure
25 bar
Temperature
-30 °C to +70 °C for liquid gas
-30 °C to +90 °C for motor fuel
- Superior discharge hose for liquid and gaseous butane, propane (LPG) or a mixture of both media
- Suitable as a reelhose
- In accordance with EN1762:2007 and DVGW NG-4621BO 0255
- Ideal for applications in which an electrical static charge can occur: classification Grade Ω
Multi Blue
Internal diameter
16 mm to 25 mm
Work Pressure
20 bar
Temperature
-40 °C to 100 °C
Applications
- Multipurpose hose for compressed air, water and aqueous solutions
- Suitable for pneumatic tooling
- Conductive tube
Multi Green
Internal diameter
6 mm to 25 mm
Work Pressure
20 bar
Temperature
-40 °C to 100 °C
Applications
- Multipurpose hose for compressed air, water and aqueous solutions
- Suitable for pneumatic tooling
- Conductive tube
Multi Red
Internal diameter
13 mm to 25 mm
Work Pressure
20 bar
Temperature
-40 °C to 100 °C
Applications
- Multipurpose hose for compressed air, water and aqueous solutions
- Suitable for pneumatic tooling
- Conductive tube
Multi Yellow
Internal diameter
6 mm to 75 mm
Work Pressure
20 bar
Temperature
-40 °C to 100 °C
Applications
- Multipurpose hose for compressed air, water and aqueous solutions
- Suitable for pneumatic tooling
- Conductive tube
Multiserv Black
Internal diameter
6 mm to 38 mm
Work Pressure
20 bar
Temperature
-30 °C to +95 °C for water applications
-40 °C to +80 °C for air and oil applications
- Premium high quality multipurpose hose handling compressed air, water and aqueous solutions, oil, diesel and other petroleum based products (not recommended for fuel applications)
- High quality multi-purpose hose for several industries
- Conductive tube, extremely flexible
- Tested according ISO 1402
Multiserv
Internal diameter
6 mm to 38 mm
Work Pressure
20 bar
Temperature
-30 °C to +95 °C
- Premium high quality multipurpose hose handling compressed air, water and aqueous solutions, oil, diesel and other petroleum based products (not recommended for fuel applications)
- Hot water cleaning hose in food industries where no food quality hose tube is required
- The grey cover is oil and grease resistant (RMA Class A)
- Conductive tube
- Tested according ISO 1402
Titon Black
Internal diameter
6 mm to 38 mm
Work Pressure
20 bar
Temperature
-40 °C to +120 °C
- High quality multipurpose hose handling compressed air, water and aqueous solutions
- Full conductive hose construction
- Tested according ISO 1402
- Complies ISO 2398:2016 type 2, Class B/L-T
Titon Red
Internal diameter
6 mm to 38 mm
Work Pressure
20 bar
Temperature
-40 °C to +120 °C
- High quality multipurpose hose handling compressed air, water and aqueous solutions
- Tested according ISO 1402
- Complies to ISO 2398:2016 type 2, Class B/L-T
Universal
Internal diameter
8 mm to 120 mm
Work Pressure
10-25 bar
Temperature
-35 °C to +100 °C
- Discharge multipurpose hose handling compressed air, water and aqueous solutions, oil, diesel and other petroleum based products having an aromatic content of max. 50% volume (not recommended for fuel applications)
Unispiral
Internal diameter
19 mm to 76 mm
Work Pressure
9-12 bar
Temperature
-35 °C to +100 °C
- Suction and discharge multipurpose hose handling compressed air, water and aqueous solutions, oil, diesel and other petroleum based products having an aromatic content of maximum 50 % by volume
- Multipurpose hose for several industries
Inferno ISO 6134-2A
Internal diameter
13 to 50 mm
Work Pressure
18 bar
Temperature
-40 °C to +232 °C
- High-pressure steam hose for saturated steam at
232 °C and 18 bar - Designed with fully conductive rubber compounds for added safety
Super Inferno
Internal diameter
19 mm to 51 mm
Work Pressure
17 bar
Temperature
-40 °C to +232 °C
- High-pressure steam hose for saturated steam at
232 °C - The best choice for steam when safety and performance are valuable
Thermoflex ISO 6134-2A
Internal diameter
19 mm - 25 mm
Work Pressure
17 bar
Temperature
-40 °C to +232 °C
- High-pressure steam hose for saturated steam
- Developed specifically for use in petrochemical and chemical refineries
Guardian
Internal diameter
13 mm to 51 mm
Work Pressure
15 bar - hot water
6 bar - open steam
Temperature
Hot water up to 90 °C
Open steam up to 164 °C
- Hot water and saturated steam hose for general industrial applications
- Hot water up to 90 °C
at 15 bar - Open steam up to 164 °C at 6 bar
Alligator SD Flexoline
Internal diameter
25 mm to 203 mm
Work Pressure
10 bar
Temperature
-35 °C to +100 °C
- Suction and delivery hose for water: sea water, waste water, ...
- Also suitable for mud, mild chemicals and fertilizer solutions in general industrial and agricultural applications
- The special construction of the hose makes it very light, extreme flexible and easy to handle
- Classification Grade Ω/T
Water Discharge Red
Internal diameter
32 mm to 102 mm
Work Pressure
10 bar
Temperature
-30 °C to +80 °C
- General purpose water discharged hose for inplant water service in general industrial and agricultural applications. Also suitable for air service
- Flexible and easy to handle
Endurance Water Discharge
Internal diameter
25 mm to 203 mm
Work Pressure
10 bar
Temperature
-30 °C to +82 °C
- General purpose water discharge hose for inplant water service in general industrial and agricultural applications. Also suitable for air service.
- Flexible and easy to handle
